Product Details

Here are some common technical specifications for the SG90 micro servo motor: 1. Operating Voltage: The range of voltage within which the servo motor can operate effectively. The SG90 typically operates at a voltage range of 4.8 to 6V. 2. Stall Torque: The maximum torque that the motor can exert when it is stalled, or prevented from rotating. The SG90 has a stall torque of approximately 1.8 kg-cm. 3. Speed: The speed at which the motor rotates, measured in revolutions per minute (RPM) or degrees per second (DPS). The SG90 has a speed of approximately 0.1 seconds per 60 degrees. 4. Operating Angle: The range of motion that the motor can achieve. The SG90 has an operating angle of 180 degrees. 5. Operating Temperature Range: The range of temperature within which the motor can operate effectively. The SG90 typically operates in a temperature range of -30 to 60 degrees Celsius. 6. Dimensions: The physical size of the motor, measured in millimeters or inches. The SG90 has dimensions
